89
96-8000 rev R June 2007
Macros
#8512 ATM. Available usage count of the next tool.
#8513 ATM. Available hole count of the next tool.
#8514 ATM. Available feed time of the next tool (in seconds).
#8515 ATM. Available total time of the next tool (in seconds).
#14401-#14406 G154 P21 additional work offsets
#14421-#14426 G154 P22 additional work offsets
#14441-#14446 G154 P23 additional work offsets
#14461-#14466 G154 P24 additional work offsets
#14481-#14486 G154 P25 additional work offsets
#14501-#14506 G154 P26 additional work offsets
#14521-#14526 G154 P27 additional work offsets
#14541-#14546 G154 P28 additional work offsets
#14561-#14566 G154 P29 additional work offsets
#14581-#14586 G154 P30 additional work offsets
#14781-#14786 G154 P40 additional work offsets
#14981-#14986 G154 P50 additional work offsets
#15181-#15186 G154 P60 additional work offsets
#15381-#15386 G154 P70 additional work offsets
#15581-#15586 G154 P80 additional work offsets
#15781-#15786 G154 P90 additional work offsets
15881-15886 G154 P95 additional work offsets
15901-15906 G154 P96 additional work offsets
15921-15926 G154 P97 additional work offsets
15941-15946 G154 P98 additional work offsets
15961-15966 G154 P99 additional work offsets
SYSTEM VARIABLES IN-DEPTH
Variables #750 and #751
These macro variables collect the input from serial port 2. The programmer can test for data queued in the serial port
2 buffer, and collect the data for processing. Macro variable #750 will inform the programmer if there is data waiting in
the RS232 port 2. A value of 1 means that the receive buffer has data queued, otherwise a value of 0 is returned.
Macro variable 751 collects the first character from the input buffer, when data is queued. This means that the buffer
content is first checked to see if it is empty; if not the value of the next character queued is returned.
1-Bit Discrete Inputs
Inputs designated as “spare” can be connected to external devices and used by the programmer.
1-Bit Discrete Outputs
The Haas control is capable of controlling up to 56 discrete outputs. However, a number of these outputs are already
reserved for use by the Haas controller.
