4&5 Axis Programming
96-8000 rev R June 2007
There are no work offsets for these axes so all commands are in the machine coordinate system. But if a displaced
zero position has been entered into the HAAS servo control, that position will be used as zero. On power-up of the
CNC, the auxiliary axes control will also be initialized and zero will be shifted by the value set in the single axis
control. To set a displaced zero, you must jog the single axis control to a new zero position and then press and
hold the Clear button on the single axis control.
Auxiliary axes communication is always seven data bits, even parity, two stop bits. The data rate is CNC Setting
54 and should be set to 4800. CNC Setting 50 must be set to XON/XOFF. Parameter 26 in the single axis control
must be set to 5 for 4800 bit per second and Parameter 33 must be set to 1 for XON/XOFF. Parameter 12 in the
single axis control should always be set to 3 or 4 to prevent circular wraparound. The cable connecting the CNC to
the single-axis control must be a DB-25 cable (male lead on both ends) and must wire at least pins 1, 2, 3, and 7
directly from the second (lower) serial port of the Haas CNC to the upper connector of the Haas servo control.
DISABLEING THE A XES
If you have a fourth-axis rotary table or 5C indexer, or a fifth axis, it should be disabled from the Settings display
when it is removed from the machine. Do not connect or disconnect any cables with the control on. If you do not
disable the rotary axis setting when it is disconnected, you will get an alarm.
