Haas Mill User Manual

Maintenance
193
96-8000 rev R June 2007
MAINTENANCE
GENERAL R EQUIREMENTS
Operating Temperature Range: 41°F to 104°F (5 to 40°C)
Storage Temperature Range: -4°F to 158°F (-20 to 70°C)
Ambient Humidity: 20% – 95% relative humidity, non-condensing
Altitude: 0-7000 ft.
ELECTRICITY R EQUIREMENTS
All Machines Require:
AC input power is three phase Delta or Wye power, except that the power source must be grounded (e.g. leg or
center leg for delta, neutral for Wye)
Frequency range of 47-66 Hz
Line voltage that does not fluctuate more than ± 10%
Harmonic distortion not to exceed 10% of the total RMS voltage
20-15 HP System (Standard VF and 10K, EC300, EC400)
195-260V Voltage Requirements 354-488V High-Voltage Requirements
Power Supply
1
50 AMP 25 AMP
Haas Circuit Breaker 40 AMP 20 AMP
If service run from elec. panel
is less than 100' use: 8 GA. WIRE 12 GA. WIRE
If service run from elec. panel
is more than 100' use: 6 GA. WIRE 10 GA. WIRE
40-30 HP System (50 Taper, 40 Taper HT 10K, VF Super Speed, EC-300, EC-400 12K, VM)
195-260V Voltage Requirements 354-488V High-Voltage Requirements
2
Power Supply
1
100 AMP 50 AMP
Haas Circuit Breaker 80 AMP 40 AMP
If service run from elec. panel
is less than 100' use: 4 GA. WIRE 8 GA. WIRE
If service run from elec. panel
is more than 100' use: 2 GA. WIRE 6 GA. WIRE
40-30 HP System (VS 1/3, HS 3-7 incl R models)
195-260V Voltage Requirements
Power Supply 125 AMP
Haas Circuit Breaker 100 AMP
If service run from ele. panel
is less than 100' use: 2 GA. WIRE
If service run from ele. panel
is more than 100' use: 0 GA. WIRE
WARNING!
A separate earth ground wire of the same conductor size as the input power is required to be connected to the
chassis of the machine. This ground wire is required for operator safety and for proper operation. This ground must
be supplied from the main plant ground at the service entrance, and should be routed in the same conduit as the
input power to the machine. A local cold water pipe or ground rod adjacent to the machine cannot be used for this
purpose.

Haas Mill Specifications

General

Travels X Axis	Varies by model
Travels Y Axis	Varies by model
Travels Z Axis	Varies by model
Spindle Speed	Varies by model
Spindle Motor	Varies by model
Table Size	Varies by model
Rapid Traverse Rates	Varies by model
Tool Capacity	Varies by model
Max Cutting Rate	Varies by model
Spindle Taper	Varies by model
