Section 7
Page 115
UVTOCMaintenance.fm Pump Tube Replacement
Figure 36 Pump Components
Figure 37 Turning the Loading Key to Insert the Tubing
1. End Bell 3. Rotor Shaft 5. Tubing Loading Key
2. Rotor 4. Tubing Grooves
1. Hold the tubing in the groove as shown. 2. Turn the Tubing Loading Key counter-clockwise.
23
4
51
2
1
