50 of 82 System Setup - 9705
KSS - March 2006 - Edition 1
Operator Manual HIAC
3) To change a setting, touch the field to change the setting.
4) Press Save and OK to save the settings and exit the Sample Settings screen.
o
e:
Press Load to reload the default settings.
Settings for the Sample Settings screen are described in Table 3-4.
Fig 3-38 : Sample Settings Screen
• Numeric entry fields invoke a keypad entry screen similar to the one shown in
Figure 3-39.
• Dropdown menu selections are made by touching the field to invoke the menu,
then touching the desired setting to highlight it.
Table 3-4 : Sample Settings Fields
Field Name Description Valid Entries
Number of runs The number of samples taken
from one bottle at one time
1 through 32
Sample Volume The volume of sample taken
from the bottle for each run
0.1 through 10000.0 mL
Tare A tare volume is a volume of fluid
that is drawn before the counter
begins counting particles. A tare
volume ensures that the sample
fluid is moving at the desired flow
rate and that no liquid meniscus
passes through the sensor
during counting operations.
Refer to “Calculating Tare
Volume” on page 48 when using
the Large Volume Adapter.
0.0 through 25.0
