Preventive Maintenance and Installation 77
Haemonetics
®
ACP-215
®
Service Manual P/N: SM-ACP215-01-EN(AB)
displays:
The device continues beeping.
8. Attach another pressure monitor test harness to SPM.
9. Attach another Bio-Tek Model DPM-11 (or equivalent) pressure meter
the pressure monitor test harness and press YES to continue. The
screen displays:
10.Install a clean and clear tubing in line sensor and close line sensor cover
and press YES to continue. the screen displays:
The device continues beeping.
CHECK CORRECT DISPOSABLE LOADED
INSTALL SPM FILTER
PRESS YES TO CONTINUE
PUMP TIME HYPE NACL ADDI
REAL: 0 0 0 0 0
TARG: 0 56 50 1470 240
CHECK CORRECT DISPOSABLE LOADED
INSTALL TUBING IN LINE SENSOR
PRESS YES TO CONTINUE
PUMP TIME HYPE NACL ADDI
REAL: 0 0 0 0 0
TARG: 0 56 50 1470 240
CALIBRATION OF LINE SENSOR
PRESS YES TO CALIBRATE
PRESS NO TO BYPASS CALIBRATION
PUMP TIME HYPE NACL ADDI
REAL: 0 0 0 0 0
TARG: 0 56 50 1470 240
