Harris DiamondCD Series User Manual

C-22 888-2463-001 3/6/08
WARNING: Disconnect primary power prior to servicing.
Diamond Series™
Appendix C Pioneer Power Supply
PM33215F-8, 5kW, Instructional manual Rev 2, 3/26/2007 20
Step 1: To remove the fan panel, follow the instruction below
Remove this screw holding the
fan panel to the bottom chassis
on the other side
Note screw size and location
Remove this screw holding
the fan panel to the bottom
chassis on one side
Note screw size and location
