WARNING: Disconnect primary power prior to servicing.
Appendix C Pioneer Power Supply
Diamond Series™
PM33215F-8, 5kW, Instructional manual Rev 2, 3/26/2007 21
Step 2: Unplug the fan cable assembly as shown
Fan wire
assembly
Unplug the fan
wire assembly
here
Step 3: Remove the fan assembly by pulling it out and replace it with the spare
One, following steps 2 and 1 in the reverse order. See section 12 for order
information.
Step 4: Remove the two product labels from the old panel and put them on the
new panel
