C-24 888-2463-001 3/6/08
WARNING: Disconnect primary power prior to servicing.
Diamond Series™
Appendix C Pioneer Power Supply
PM33215F-8, 5kW, Instructional manual Rev 2, 3/26/2007 22
Section 12 Ordering parts for Field Repairs
PMI Part # Description
533033 Fuse F1, 20A, 250V, 3AB Normal Blo
124664-1 Complete Fan Assembly Including Labor
124203 Fan Panel
429006 Fan Guard 4.5” 8 ring
466044-0075 Screw Pan Hd Phil 4-40X3/4
471115 Nut Shakeproof 4-40
476111-0004 Washer Flat #4
122480-6 Wire Assembly J1 to Fan) 6”
510047 Fan Muffin 140CFM 24VDC Ball Bearing
442000-0125 Heat shrink sleeving blk 1/8
1. Fuse F1 specification on next page
2. Price and availability provided on request
Contact Information to order parts:
Customer Support
Tel: 310 829 6751 x 222
Fax: 310 453 3929
E-mail: asheth@pioneermagnetics.com
