FAQs: Frequently asked questions (MP85A and PME Assistant)
116 A0293_06_E00_03 HBM: public MP85A
► Via the Windows Start menu go to Settings  Network Connections. From
the context menu (right-click), select the Properties of the desired LAN con
nection.
► Select Internet protocol (TCP/IP) and click on Properties.
► Click on Use the following IP address and enter an address in which the
first three groups of digits match those of the MP85A and only the last
group of digits contains a different number between 1 and 254. The last
group of digits must not match the group of digits in the MP85A!
► For the Subnet mask, enter the same groups of digits as the MP85A.
► Then click OK to close all open dialogs. You may have to restart the PC to
enable the setting.
Example:
The IP address of the MP85A is 192.168.169.80, the subnet mask is
255.255.255.0.
► On the PC, enter 192.168.169.123 as the IP address and 255.255.255.0 as
the subnet mask.
13.3 How do I connect the PME Assistant to the MP85A?
Tip
The interface must be installed and configured.
Procedure
1. Switch on the power supply to the PME device(s).
2. Connect the PC interface to the PME device(s).
3. Launch the PME Assistant.
4. Enter the interface you are using.
CAN bus: If applicable, select the CAN network you are using (Change).
