FAQs: Frequently asked questions (MP85A and PME Assistant)
MP85A A0293_06_E00_03 HBM: public 139
13.18 What do the error messages for tolerance window
violations mean?
If the specified entry and exit sides of a tolerance window are violated, several
possible error messages may be shown. To make it easier for you to under
stand the relevance of the error messages, the diagrams below show exam
ples of possible (incorrect) curves.
Exit condition not fulfilled
Exit before inset condition fulfilled
