FAQs: Frequently asked questions (MP85A and PME Assistant)
136 A0293_06_E00_03 HBM: public MP85A
Load parameter set
Time necessary for changes
typ. < 200 ms
(Level change at bit0 ... bit4)
Loading parameter set
Notes
S Only level changes , i.e. the edges, are analyzed at the inputs.
S Switchover must be complete before you can start a new process. To
check, use the “Loading parameter set” signal.
13.16 How can I find out/track changes to device settings?
Via the Options Change log menu, you can track changes to the configu
ration that took place using this PC and by the currently logged in (Windows)
user. When this option is enabled, all changes are logged in encrypted form
(internal parameter IDs) in the ChangeLog.LOG file. The file is created in the
storage folder.
To disable this option, enter the same password as when you enabled it.
