Communication with a control system
MP85A A0293_06_E00_03 HBM: public 103
10.8 Process data backup/production data management
For quality control purposes, all process data can be saved. You can save
process curves and/or process results and statistical data (separate files). This
data can be saved internally on the memory card or externally to a PC via the
bus interface. You can define which data is saved in the PME Assistant in the
“Data backup” area or with the INDUSTRYmonitor or EASYmonitorCE pro
gram.
If the data is to be saved on the memory card, you have a choice of two meth
ods (in both cases, data can be transferred from the memory card to the PC
followed by a display):
1. Ring buffer for the last 1,000 or 10,000 processes.
2. Unlimited storage up to the capacity of the memory card.
Example: With a 2 GB MMC/SD card and typical process curves of approx.
3 kB, up to 600,000 processes can be stored.
Directory/
component number
Production
monitoring
with MP85A
Internal MMC/SD
CANopen
PROFIBUS (DP)
Profinet-RT (DP-PN)
Directory/
component number
You can also add a component designation to the file name of saved process
data and saved it in directories of your choice on the destination system. This
enables efficient production data management. The information is transferred
to the MP85A process controller via the PME Assistant, the INDUSTRYmonitor
or the bus interface.
