Starting up/Setup mode
52 A0293_06_E00_03 HBM: public MP85A
7.1 Operation
7.1.1 Device settings, measured values, process status, PROFIBUS,
memory card, error types, firmware update, device backup
The display of the MP85A process controller shows measured values and
status information for measurement channels, process status, digital inputs/
outputs and parameter set backup; devices with PROFIBUS interface also
show the PROFIBUS status.
You can switch between individual displays and menus with the device
keyboard.
Use the device menu to set the Ethernet, CAN bus or PROFIBUS addresses.
In addition, a menu is available for device identification (serial number,
firmware and hardware version, etc.) and for backing up the 31 flash parameter
sets.
All other device settings take place in the software via the PME Assistant or
INDUSTRYmonitor program.
Display in measuring mode:
-18.0024
kg
Measured value
Unit
Status field
!
