Installing/removing the MP85A (schematic diagrams)
MP85A A0293_06_E00_03 HBM: public 19
Fig. 4.2 Removal
Important
The support rail must be connected to a grounded conductor .
Fig. 4.3 Installing a second spring for more stable fastening of the MP85A process
controller on the support rail
