Switch test (EASYswitch)
MP85A A0293_06_E00_03 HBM: public 89
For the haptic test, the curve must enter and exit the window at the sides and
the window must always be rectangular. The curve is not permitted to enter or
exit the window at the top or bottom.
Tip
For additional security, you can set up additional progress windows to evaluate
the process curve in real time, which helps to protect the machine. With a
potentially faulty switch, a limit force shutdown takes place with a response
time of approx. 2 ms.
You can find further information in the PME Assistant online help and the inter
face description of the MP85A process controller.
