104
5. Press the Enter button.
✓ The display will change to the first parameter specific to that
hydraulic system.
6. Use the Plus or Minus button to select the desired setting.
7. Press the Enter button.
✓ The selected parameter has been confirmed.
✓ The next parameter will be called up.
8. Repeat steps 6 and 7 for all hydraulic-specific parameters.
9. Use the Menu button to exit the parameter group 8-Hydraulic
systems.
✓ The hydraulic system has been configured.
✓ The display switches to the menu selection.
CHECKING THE ACTUATORS IN MANUAL OPERATION
1. Switch to manual operating mode.
✎ See chapter “6 Using the heating system”, section “6.6 Changing
operating mode”.
2. Check that the following actuators work properly:
• Delivery system h-01
• Delivery system h-02
• Automatic grate h-03
• Grate h-04
• Cleaning h-05
• Stoker auger h-06
• Cleaning h-06a
• Combustion fan h-07
• Suction h-08
• Ignition h-09
• Return valve h-10
All parameters specific to the installed hydraulic system are called
up successively.
For an overview of the hydraulic systems with their hydraulic-
specific parameters, see chaper “4 Planning and installation”,
section “4.10 HDG hydraulic systems”.
