HDG Pelletmaster 15 - Fitting the Cover to the Technical Components

4 Planning and installation – Installing the heating system
63
FITTING THE COVER TO THE TECHNICAL COMPONENTS
1. Undo the 17 mm nut (1) on the lid brace (2).
2. Connect the cover of the technical components with the bearer of
the control panel.
3. Attach the connection cable plug (2) to the control unit (3).
Figure 4/47 - Fitting the left cover
1
2
Figure 4/48 - Fitting the cover to the technical components
2
3
1
