3 Mode of operation – Overview
15
HDG PELLETMASTER 15/25 SIDE VIEW
1 Suction turbine
2 Pellet vacuum container
3 Cleaning shaft lid with suction fan
4 Combustion chamber door
5Ash removal
6Stepped grate
7Combustion fan
8 Pressure equalisation hoses
9 Ignition fan
10 Feed system
Figure 3/2 - HDG Pelletmaster 15/25 side view
