36
1Seal
2Access hatch
3Z-shaped retainer
4 Wooden boards (supplied by customer)
5 Separating wall
Doors and access hatch must have a seal to prevent dust from
escaping when pellets are being blown in. On the door to the pellet
bunker, wooden boards must be fitted on the inside (at least 3 cm,
tongue & groove design if possible), so that the pellets can't press
against the door.
ALTERNATIVE PELLET STORAGE OPTIONS
STORAGE IN A BURIED TANK An option for storing the pellets outside of the building to keep them
dry and dust-free is the use of a tank which can be buried in the
garden.
Figure 4/9 - Access to the pellet bunker
