122
INFORMATION LEVEL
No. Display Description
Terminal module: 0
851321376 V0.3
50 k Baud
Establishing conn.
• Switch-on message
Is shown for about 10 seconds after the power switch is
turned on.
i-01 Control
Combustion ctrl.
Boiler 60/65°C
Return 60/60°C
• Operating status
Configured control type
Boiler temperature set/actual
Return temperature set/actual
i-02 Control
FIRE 800/790°C
O2 7.0/7.4%
Material 50/50%
• Operating status
Temp. of combustion chamber set/actual
Residual oxygen set/actual
Fuel quantity set/actual
i-03 Control
Outdoor temp. 6/
6°C
Exhaust gas
temp. 110°C
• Operating status
Outdoor temperature averaged/current
Current exhaust temperature
i-04 Times
Control
00:00:00
• Times
Current durations of the operational states
i-05 Requirement
External 0°C
Buffer 80°C
• Required preset boiler temperature
via an external contact
via buffer
i-08 Boiler
Material 50/50%
Comb. fan 60/70%
Suction fan
80%
• Boiler display
Fuel quantity set/actual in %
Speed of combustion fan set/actual
Current speed of suction fan
i-09 Boiler control
O2 7.0/7.4%
CorrO2 +100%
RampO2 -20%
• Boiler control parameters
Residual oxygen (O2) content set/actual
Internal control value
Internal control value
i-10 Return increase
Mixer control
Return: 60/60°C
Pump On
• Return flow increase
Return temperature set/actual
Pump status (on/off)
Table 6/2 - Information level
