6 Using the heating system – Structure of the menus
123
i-11 Buffer
Status
heating
Temp. at top
37°C
Temp. at bottom
25°C
• Buffer information
Buffer status
Temperature at top of buffer tank
Temperature at bottom of buffer tank
i-12 Heating circuit 1
Heating
Supply: 57/56°
Mixer: Closed HCP: On
• Information for heating circuit CCT1
Operational state of heating cct.
Supply temperature set/actual
Mixer status Closed/Open Heating cct. pump status
On/Off
i-13 Heating circuit 2
Heating
Supply: 59/54°
Mixer: Closed HCP: On
• Information for heating circuit CCT2
Operational state of heating cct.
Supply temperature set/actual
Mixer status Closed/Open Heating cct. pump status
On/Off
i-14 Heating circuit 3
Heating
Supply: 65/65°
Mixer: Open HCP: On
• Information for heating circuit CCT3
Operational state of heating cct.
Supply temperature set/actual
Mixer status Closed/Open Heating cct. pump status
On/Off
i-15 Heating circuit 4
Heating
Supply: 63/65°
Mixer: Open HCP: On
• Information for heating circuit CCT4
Operational state of heating cct.
Supply temperature set/actual
Mixer status Closed/Open Heating cct. pump status
On/Off
i-16 Heating circuit 5
Heating
Supply: 66/65°
Mixer: Open HCP: On
• Information for heating circuit CCT5
Operational state of heating cct.
Supply temperature set/actual
Mixer status Closed/Open Heating cct. pump status
On/Off
i-17 Heating circuit 6
Heating
Supply: 66/65°
Mixer: Open HCP: On
• Information for heating circuit CCT6
Operational state of heating cct.
Supply temperature set/actual
Mixer status Closed/Open Heating cct. pump status
On/Off
i-18 Boiler 1
Boiler heating
Set: 60°C Pump:On
Top/bottom 53/20°C
• Information for boiler 1
Boiler 1 is heating
Set temperature for boiler 1 Pump status On/Off
Temperature of boiler 1 at top/bottom (only for solar)
No. Display Description
Table 6/2 - Information level (continuation)
