i-19 Boiler 2
Boiler heating
Set: 60°C Pump:Off
Top/bottom 60/58°C
• Information for boiler 2
Boiler 2 is heating
Set temperature for boiler 2 Pump status On/Off
Temperature of boiler 2 at top/bottom (only for solar)
i-20 Solar 1
Collector temp:32°C
Solar pump 1: 60%
Solar p. buffer: 0%
• Solar information
Solar collector temperature
Speed of solar pump 1
Solar pump for buffer
i-21 District heating 1
Temp. dist. heating
65°C
Dist.htg. pump off
• Information on district heating
Transfer temperature of district heating
Status of district heating pump
i-22 Oil-fired boiler 1
Temp. of oil-fired
boiler 20°C
Oil-fired boiler On
• Information on oil-fired boiler
Temperature of oil-fired boiler
Status of oil-fired boiler On/Off
i-23 Delivery
Full
M-protect 1 full 1
Stoke time 20:30
• Delivery system
Fill level of intermediate pellet container empty/full (0/1)
Motor protection OK yes/no
Stoker running time until next filling of pellet vacuum
container
i-24 Fill container
Enabled 0/1
Del. auger runtime
105m
• Fill container
Enable time enables vacuum delivery system yes/no,
Running time for delivery auger (tank will be filled
in 105 min)
i-25 Grate
off
Limit switch
Start in: 02:25
• Grate information
ON/OFF
Limit switch
Next grate movement in ...min
i-26 Cleaning
Enabled 1
Status: Run
Runtime: 00:00
• Cleaning of heat exchangers
Status
Next cleaning in ... hours
i-27 Operating hours
Boiler 26 h
Stoker auger 3 h
Delivery 0 h
• Display of operating hours
Operating hours when system is turned on
Actual running time for stoker auger
Actual running time for delivery system
i-27a Cleaning
Ash auger: 0 h
Start in: --:--
• Display of operating hours for cleaning
Actual running time of ash auger
Next start in . . . hours
No. Display Description
Table 6/2 - Information level (continuation)
