HemoCue 201 DM Reference Manual

38
Enter
Settings Password
123123ABCABC
4
3
2
FIGURE 3-2
Only displayed if the Operator ID
requirement at startup is set to “Not used”
(see 3.4.1 General Settings)
c) Enter the Settings Password (default value
is “0000”), either directly on the Display
via the Text mode(2) and Numeric
mode(3) buttons, or with the Barcode
Scanner via the Barcode Scanner
button(4).
d) If the wrong password is entered, FIGURE
3-3 will be displayed.
If the correct password is entered FIGURE
3-4 will be displayed.
2 Text mode button
3 Numeric mode button
4 Barcode Scanner button
Settings
Incorrect
Password or User
Level
No Changes to the
Settings will be
Saved
6
5
FIGURE 3-3
e) Pressing the Previous image button(5)
will result in a return to, either the Main
Menu (if the operator’s user level does
not permit access to the Settings), or
FIGURE 3-2 (if the Operator ID is set to
“Not Used”).
Pressing the Confirm button(6) allows
the Settings to be viewed only. FIGURE
3-4 will be displayed.
In this “view only” mode, the pressing of any
button will highlight the option but no
change will be eected.
5 Previous image button
6 Confirm button
