July 2017 PLT-01067, Version: A.7
Reader Configuration Page 8-7
4. Enter the Application Properties.
MIFARE 1k / MIFARE 4k Application Properties Window
The following window appears when the MIFARE (1k or 4k) Card Technology has been selected.
Field Description
Application ID (HEX) Enter an Application ID (3-byte Hex value).
Sector The Sector number box sets the sector number where the application is
loaded.
Range is: 1k: 0 - 15 4k: 0 - 39
Sectors to Read Instructs the encoder on the number of consecutive sectors to be read.
Range is: 1k: 0 - 15 4k: 0 - 39
Data Offset Instructs the encoder on the number of bytes to ignore before applying
subsequent data manipulation operations.
MIFARE Key Type Select from the drop-down menu. Options are: Key A or Key B.
Auth Key Sets the actual custom key to be loaded to the encoder for authenticating
the read operation.
Note: The keys in this list are created in the Create a Key process. Only keys
created with the Key Size for that technology appears. For example a key
created with a 6 Byte size would appear for MIFARE.
