Page 8-8 Reader Configuration
PLT-01067, Version: A.7 July 2017
MIFARE DESFire 0.6 / MIFARE DESFire EV1 Application Properties Window
The following window appears when the MIFARE DESFire (.06 or EV1) Card Technology has
been selected.
5. When the Application Properties wizard is complete, click Next.
Field Description
Application ID (HEX) Enter an Application ID (3-byte Hex value).
File Number Range is 0 - 31
File Size Range is 0 - 240 bytes
Data Offset Range is 0 - 256 bits
MIFARE DESFire Key
Number
Select from the drop-down menu. Options are Key 0 through Key 13 or select
Free File Access if authentication is not required.
Auth Key Select key from the drop-down field.
Note: The keys in this list are created in the Create a Key process. Only keys
created with the Key Size for that technology appears. For example a key
created with a 16 Byte size would appear for MIFARE DESFire.
Crypto Method Options are: None, DES, or AES (AES is available with MIFARE DESFire EV1
only).
Key Diversification
Algorithm
Options are: None, NXP AV1 1KTDES, NXP AV1 2KTDES, or NXP AV1 AES128
(AES 128 is available with MIFARE DESFire EV1 only).
File Transmission Type Options are Plain or Cipher.
