DS-1100KI Network Keyboard User Manual
95
Num =0 means cancelling the image display of the window. Clicking the window area directly can also
select the window.
Num + MON, Num + WIN and Num + CAM keys are available. PTZ control can be realized via the joystick.
Press i + MON and NEXT/PREV keys to switch to the next/previous screen.
1. Configure all the channels of NVR well before operator linkage. If modifying, adding or deleting IP cameras of
NVR after linkage, the automatic synchronous update will not function.
2. Screen switch action, that is to press PREV/NEXT keys, just means the operation of switching to the
previous/next screen. It is not guaranteed to keep the keyboard and the local live view consistent (e.g. The
local live view image has been switched to the second screen, but the keyboard still displays the first
screen.).

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
