Hill-Rom Basic Care P1440 - Casters for Individual Brake and Steer; Removal

4.25 Casters for Individual Brake and Steer
Chapter 4: Removal, Replacement, and Adjustment Procedures
Basic Care™ Bed Service Manual (man336) Page 4 - 59
4
4.25 Casters for Individual Brake and Steer
Tools required: Phillips head screwdriver
Caster blocks
Bed frame jack
Removal
1. Disconnect the battery cable from the control board (refer to procedure 4.7
on page 4-16).
SHOCK HAZARD:
Disconnect the bed from its power source. Failure to do so could result
in personal injury or equipment damage.
2. Disconnect the bed from its power source.
WARNING:
Put caster blocks behind the casters at the opposite end of the bed.
Failure to do so could result in personal injury.
3. Put caster blocks behind the casters at the opposite end of the bed that you
are working on.
4. Use a jack to lift the end of the bed you are working on off of the floor.
5. Remove the bolt (A) and washer (B) attaching the caster (C) to the bed
frame (D) (see figure 4-26 on page 4-60).
6. Remove the caster (C) from the bed frame (D).
