4.3 Trendelenburg Control Box
Chapter 4: Removal, Replacement, and Adjustment Procedures
Basic Care™ Bed Service Manual (man336) Page 4 - 7
4
4.3 Trendelenburg Control Box
Tools required: 3 mm Allen™
1
wrench
Needle nose
Removal
SHOCK HAZARD:
Disconnect the bed from its power source. Failure to do so could result
in personal injury or equipment damage.
1. Disconnect the bed from its power source.
2. Disconnect the battery cable from the control board (refer to procedure 4.7
on page 4-16).
3. Remove the two retaining rings (A) attaching the Trendelenburg and
Reverse Trendelenburg rods (B) to the switches (C) (see figure 4-3 on page
4-8).
4. Remove the two screws (D) attaching the Trendelenburg control box (E) to
the bed frame (F).
5. Remove the Trendelenburg control box (E) from the bed frame (F).
1. Allen™ is a trademark of Industrial Fasteners, Inc.
