4.17 Siderail Slide Bracket
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 40 Basic Care™ Bed Service Manual (man336)
4.17 Siderail Slide Bracket
Tools required: 5 mm Allen™
1
wrench
Wire cutters
Removal
SHOCK HAZARD:
Disconnect the bed from its power source. Failure to do so could result
in personal injury or equipment damage.
1. Disconnect the bed from its power source.
2. Disconnect the battery cable from the control board (refer to procedure 4.7
on page 4-16).
3. Remove the two screws (A) attaching the siderail (B) to the bed (see figure
4-17 on page 4-41).
4. Pull the slide bracket (C) out of the siderail (B) (see figure 4-17 on page 4-
41).
1. Allen™ is a trademark of Industrial Fasteners, Inc.
