4.16 Siderails
Chapter 4: Removal, Replacement, and Adjustment Procedures
Basic Care™ Bed Service Manual (man336) Page 4 - 39
4
b. Remove the siderail (C) from of the bed frame (H).
c. Go to “Replacement” on page 4-39.
7. If the siderail is a headrail (A) on an electric bed, do the following:
a. Remove and discard the label (I) on the inside of the siderail control
assembly (J).
The new headrail comes with a new label for the inside of the siderail control
assembly.
b. Remove the siderail control assembly (J) (refer to procedure 4.19 on
page 4-44).
c. Remove the two screws (F) and the slide bracket (G) attaching the
headrail (A) to the bed frame (H).
d. Remove the headrail (A) from of the bed frame (H).
Replacement
1. Do the removal procedure in the reverse order.
2. Do the “Function Checks” on page 2-2.
