4.13 Head or Knee Crank Rod and Drive Screw Assembly (Manual Model Only)
Chapter 4: Removal, Replacement, and Adjustment Procedures
Basic Care™ Bed Service Manual (man336) Page 4 - 31
4
12. Remove the two bolts (L) attaching the drive screw assembly (H) to the
bed frame (B).
Replacement
1. Do the removal procedure in the reverse order.
2. Do the “Function Checks” on page 2-2.
