4.18 Siderail Retraction Assembly
Chapter 4: Removal, Replacement, and Adjustment Procedures
Basic Care™ Bed Service Manual (man336) Page 4 - 43
4
WARNING:
Wear eye protection. Failure to do so may result in eye injury.
4. Put on eye protection.
5. Remove the two screws (D) attaching the top cane (E) to the siderail (A).
6. Remove the two spring assemblies (F) from the siderail (A).
Replacement
1. Do the removal procedure in the reverse order.
There are both left-hand and right-hand siderail retraction assemblies.
2. Do the “Function Checks” on page 2-2.
