Hill-Rom Basic Care P1440 - Replacement

4.2 Control Panel, Foot End
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 6 Basic Care™ Bed Service Manual (man336)
CAUTION:
Use caution when cutting wire ties. Failure to do so could result in cable
damage.
3. Carefully cut all of the wires ties on the two cables (C) from the foot end
control panel (A) to the bed frame (D).
4. Disconnect the two cables (C) from the control box assembly (B).
5. Remove the footboard (E) from the bed frame (D).
6. Remove the two screws (F) attaching the foot end control panel (A) to the
bed frame (D).
7. Remove the foot end control panel (A) from the bed frame (D).
Replacement
1. Do the removal procedure in the reverse order.
2. Do the “Function Checks” on page 2-2.
