Hill-Rom Basic Care P1440 - Replacement

4.27 Sleep Surface Panels
Chapter 4: Removal, Replacement, and Adjustment Procedures
Basic Care™ Bed Service Manual (man336) Page 4 - 63
4
b. Remove the two retaining rings (C) and two pins (D) attaching the foot
panel (F) to the bed frame (E) (see figure 4-28 on page 4-62).
c. Remove the foot panel (F) from the bed frame (E).
5. If you are replacing a head panel (H), do the following.
a. Remove the two headrails (I) from the bed frame (E) (refer to
procedure 4.16 on page 4-37).
b. Remove the CPR handle assembly (J) from the bed frame (E) (refer to
procedure 4.15 on page 4-35).
c. Remove the two retaining rings (C) and two pins (D) attaching the head
panel (H) to the bed frame (E) (see figure 4-28 on page 4-62).
d. Remove the head panel (H) from the bed frame (E).
Replacement
1. Do the removal procedure in the reverse order.
2. Do the “Function Checks” on page 2-2.
