Bed Frame Features
Progressa™ Bed User Manual (171528 REV 1) 43
4. Make sure the transport handles are up and locked in position.
5. Unplug the bed from its power source.
6. Unplug and stow all power cords and communication cords on
the hook at the bottom of the transport handle.
7. Set the steer pedal to Steer (step down on the green brake pedal
until it stops).
NOTE:
Unplugging the bed, and putting the bed in steer mode will
automatically deploy the drive wheel, but will not power the IntelliDrive® Transport System.
8. Grip one or both of the transport handles located at the head end of the bed.
9. Press at least one of the enable switches on the underside of the blue transport handles.
• Pressing an enable switch engages the drive wheel on
the bed so it can move when pressure is applied to the
handles.
• Pressing an enable switch will not cause the bed to start
moving if there is no pressure applied to the handles.
10. Push the transport handles forward to start forward
movement or pull them toward you to start reverse
movement. There may be a momentary delay before the
bed moves.
• Pressure sensors located in the transport handles sense
the applied pressure, activate the motor, and propel the bed in the direction of applied
pressure.
• The amount of applied pressure to the handles will regulate the speed of the bed.
– Increasing the forward applied pressure will move the bed forward faster. Maximum
forward speed is between 2.5 and 3.5 mph on level flooring.
– Increasing the reverse applied pressure will move the bed in reverse faster. Maximum
reverse speed is between 1.0 and 2.0 mph on level flooring.
11. Decreasing pressure on the transport handles will slow the bed down.
12. Releasing the enable switch(es) on the transport handles will cause the bed to stop.
To deactivate the IntelliDrive® Transport System
1. Set the brake/steer system to neutral or brake, or
2. Plug the bed into an appropriate power source.
Sequence label—located
between the transport
handles.
