Factory defaults
NOTE Factory defaults are the settings in the device when it comes off the
manufacturing floor. Customized configuration files modify these defaults based
on preferences for specific sites. Restoring default settings on a device returns it to
its manufacturing floor defaults, not the custom configuration.
Device
Settings Default value
Active Config file name Factory
Device location displayed Yes
First-time startup screen displayed Yes
Touchscreen lockout interval 2 minutes
Auto sleep mode allowed Yes
Sleep mode duration 2 minutes
Auto shutdown allowed Yes
Auto shutdown timeout 15 minutes
Display brightness 5
Touchscreen calibration 55, 57, 4003, 3993, 193, 3910, 200, 3900
(array of 8 integers)
Splash screen Hillrom logo
Load new software on power cycle enabled No
Load new software to device Greyed out
Screen off allowed Yes
Screen off timeout 1 minute
Power line frequency
60
1
1
Power line frequency can be modified in the Configuration Tool to support specific parameters like Masimo
SpO2. With both new and existing configurations, follow these steps:
1.
Navigate to the Progress Summary page.
2. Scroll down to Section: Biomed (Required) at the bottom of the page and click General Device
Settings.
3. Select Custom.
4. Scroll down to Other on the General Device Settings page and select the desired Power Line
Frequency.
142 Appendix Welch Allyn® Connex® Spot Monitor
