Service Kit
Number
Material
Number
Description
10 105925 Srv Kit CSM, Main PCA, and LCD Frame
11 105930 Srv Kit CSM, Power Harness
12 105938 Srv Kit CSM, Newmar Antenna PCBA
13 105936 Srv Kit CSM, Newmar Radio PCBA
14 105937 Srv Kit CSM, Bluetooth Radio PCBA
15 105926 Srv Kit CSM, Masimo SpO2 Insert
16 105927 Srv Kit CSM, Nellcor SpO2 Insert
17 105928 Srv Kit CSM, No SpO2 Insert
18 105929 Srv Kit CSM, Nonin SpO2 Insert
19a
108241
Srv Kit HW A-F, LCD with Touchscreen
19b
108121
1
Srv Kit CSM, Combined LCD with Touchscreen New
20 105922 Srv Kit CSM, LCD Bezel
21 105921 Srv Kit CSM, Front Housing
22 105941
Srv Kit CSM, Braun ThermoScanPRO 6000 Module
2
23 105940 Srv Kit CSM, Sure Temp Plus Module
24 105943 Srv Kit CSM, APM Work Surface
25 Batt99 Srv Kit 9 Cell Lithium Ion Battery
26 105972 Srv Kit CSM, APM Work Surface, Battery Door
27 7000-PS Connex Spot Power Supply
* Not available for direct purchase.
1
When using the 108121 (Srv Kit CSM, Combined LCD with Touchscreen New), you are required to upgrade
your device with the newer 409703-18 CSM Main Board, the new LCD Touchscreen, and to upgrade the
software to 1.41 or greater. Contact Welch Allyn for further details.
2
When using a replacement service kit (Srv Kit CSM, Braun ThermoScanPRO 6000 Module) in China substitute
108189 for 105941. This kit contains the new software version 5.28.
About 3rd Edition service kits
The tables describes the components of the device and APM and the associated service kits for
replaceable parts for devices manufactured per IEC60601-1 3rd Edition from 2015 through 2018. To
determine which year your device was manufactured in, refer to the serial number. The year of
manufacture is listed as the last two digits of the serial number.
92 Field replaceable units Welch Allyn® Connex® Spot Monitor
