Page #256 background imageLoading...
Page #256 background image
PCBA identifier XXXXXX BOM Y DWG Z
XXXXXX Welch Allyn material number
Y Bill of material (BOM) revision
Z Assembly drawing version from current version of
drawing
Circuit board and internal option labels
Serial number XXXXWWYYID
XXXX Sequential number
WW Week of manufacture
YY Year of manufacture
ID Unique vendor identifier
Model number format and code
Model configuration
NOTE Some model numbers and product features described in this publication
might not be available in your country. For the latest information about products
and features, please contact Hillrom Customer Care.
NOTE For more configuration options, including approved accessories, see the
accessories list in the Instructions for use on the user documentation CD or https://
direct.hill-rom.com/hillromUS/en.
NOTE If options have been added to the device, the actual configuration will not
match the model description.
The device has multiple configurations. Use the following table to determine 7100, 7300, 7400, and
7500 model configurations. Not all configurations may be available. Model numbers include one
item from each column.
Examples: 75CE-B (North America), 71XE-4 (United Kingdom)
Model Parameter Power cord
SpO2 Temperature
71 = 7100 Value series W = Nonin
X = Blank / None
E = Braun ThermoScan
PRO 6000 IR
T = SureTemp Plus
X = Blank / None
A = Denmark
B = North America
C = China
G = Argentina
250 Identifying the monitor and subsystems Welch Allyn® Connex® Spot Monitor
