● Transmission Sequences 6-23
(3) Print format
a） Print format text structure
¡ Specifying no print items
Print format text
¡ Two or more print specification items can be consecutively transmitted in a single chain.
¡ Specifying the print items
¡ Character size and inter-character space
¡ Bar code type
ESC Header 24H Item number Print format text
Item number selection (1 to 100)
ESC Header 22H
Line Line
count spacing
Line count Line spacing
（1 to 4）（0 to 2）
Set actual item number data as
indicated in the example below.
If the software option "Print digit
addition" is not used, ensure that the
item number does not exceed 24.
Item number1...31H
Item number2...32H
¡ Target sensor filter
ESC Header 38H
Thousands Hundreds
Tens position Units position
position position
Target sensor filter（0000 to 9999）
b）Setup items
¡ Line count and Line spacing
ESC Header 21H
Character
Inter-character
size space
Character size（0 to 5）Inter-character space（0 to 8）
ESC Header 2AH Type
Bar code type（30H to 3CH）
Character size
0：5×5
1：5×8（5×7）
2：7×10（9×8、9×7）
3：12×16
4：18×24
5：24×32
Bar code types
30H：Code39
31H：ITF
32H：NW-7
33H：EAN-13
34H：DM16×16
35H：DM8×32
36H：Code128
37H：DM16×36
38H：DM16×48
39H：DM18×18
3AH：DM20×20
3BH：DM22×22
3CH：DM24×24
ESC Header 39H Division
Division （1: time setup, 2: until end of print.）
¡ High-speed printing
ESC Header 3AH Mode
Mode (0: HM, 1: NM, 2: QM)
ESC Header 3BH Based
Based (0: Time-based, 1: Encoder based)
¡ Product speed matching
¡ Pulse rate division Factor
ESC Header 3CH
Hundreds
Tens position Units position
position
Pulse rate division Factor（001 to 999）
¡ Ink drop use percentage
ESC Header
3DH
Tens Unit
position position
Ink drop use percentage（01 to 16）
