(1) Use the tweezers to hold the O-ring and put it into
the nozzle body.
(2) Use the cleaning bottle and splash a few droplets
of makeup ink on the O-ring.
(3) Insert the orifice plate and use tweezers to lightly
depress the plate from the top.
(4) Remove the orifice plate once and make sure that
the O-ring has been installed.
(5) Reinsert the orifice plate, and use the
four screws to secure it.
¡
Use the four screws to secure the
orifice plate so that the characters on it
face up.
¡
Tighten the four screws little by little
alternately.
(6) Reinstall the charge electrode and deflection
electrode.
