7-35 ● Excitation Setting Adjustment
The "Excitation V update" screen then opens.
12345678 90
Excitation V update 2011.07.07 12:45
Excitation V-ref. [１１] (０〜１９)
Ref. ambient temperature ２３ (℃)
Automatic update [２] (0: disable 1: Decrement 2 : Increment )
Incremental change [１] (1-9)
Print trigger source [２] (1: Button input 2: Sensor )
Print data [２] (1: For test 2: Data to be displayed)
Perform nozzle property test and find the optimum excitation
voltage value.
Back
←
→
↑
↓
Nozzle test
Decre-
ment
Incre-
ment
Status : Standby Com=0
Manual
Start
up
Shut
down
Comm
On/Off
Show
cursor
If the cursor is not
displayed, press
Show cursor .
3
Set up the "Print trigger source".
Set up the timing for performing printing.
1: Button input → Print on "Start printing" on the control panel.
2: Sensor → Print on a sensor signal.
4 Verify that the printer is in "Standby" state. Press Nozzle test .
The "Nozzle property test" screen then opens.
Nozzle property test 2011.07.07 12:45
Excitation V-ref. [１１] (０〜１９)
Ref. ambient tempereture ２３ (℃)
Automatic update [２] (0: disable 1: Decrement 2 : Increment )
Incremental change [１] (1-9)
Print trigger source [２] (1: Button input 2: Sensor )
Print data [２] (1: For test 2: Data to be displayed)
Excitation V-ref. is printed on the print target.
[ ｎｎ・・・・・・]
Printing starts upon signal from sensor.
↑
↓
Abort
Decre-
ment
Incre-
ment
Status : Ready Com=1
Print data can be set.
1: For test: Print will be performed automatically under the following conditions:
Number of lines : 1 line
Character size : 12 X 16 dots
Inter-character space : 1
Character height : 99
Character width : 5
Ink drop use percentage : 1/3
Print description :■■nn123ABC
(nn shows excitation V-ref..)
2: Data to be display: Print will be performed in the print condition, and with
content, currently set.
