Hitachi PXR-D User Manual

13-2 ●Outside Dimensions
Fig. 13-2 Print head outside dimensions (65μm nozzle machine)
Printed surface
Theoretical lowest dot position
Direction of ink deflection
Direction of ink ejection
Lowest dot position
Printing distance
Print head cover
Nozzle center
Print head cover retaining thumb screw (φ10)
91
16
91
16
6-M3
91
8-M4
16
2-M3
Overall weight of print head: 2.5kg
(cable: 1.8kg, print head tip portion: 0.7kg)
40 2
26
47
40
105
5
228
13
18
24
2-M4
31
31
6
L
H
LH
10
20
16.5
17
