●Outside Dimensions 13-3
Fig. 13-3 Print head outside dimensions (40μm nozzle machine)
Printed surface
Theoretical lowest dot position
Direction of ink deflection
Direction of ink ejection
Lowest dot position
Printing distance
Print head cover
Nozzle center
Print head cover retaining thumb screw (φ10)
91
16
91
16
6-M3
91
16
2-M3
Overall weight of print head: 2.5kg
(cable: 1.8kg, print head tip portion: 0.7kg)
2
40
26
47
40
90
5
213
8-M4
18
13
2-M4
31
31
24
6
L
H
LH
5 15.5
