Hitachi YUTAKI RWM-2R1E User Manual

8.2.3 Icons for the room thermostat view
Icon Name Explanation
Manual/Auto mode
Manual mode
Auto mode with timer setting
Auto mode without timer setting
Setting/Room
temperature
Setting temperature
Room temperature
End of timer period The end hour of the timer period is indicated below this icon
End of holiday period The end hour of the holiday period is indicated below this icon
Setting temperature This icon appears while the setting temperature is being changed, and indicates the actual temperature
Next screen
When room thermostat has been congured for both circuit 1 and 2, this icon appears at the right side of the
screen to indicated that there is a 2nd room thermostat view
UNIT CONTROLLER (PC-ARFH1E)
PMML0575 rev.2 - 03/2022
128
