13 MAINTENANCE
13.1 REMOVING THE COVERS
If it is necessary to access to the indoor unit components, please follow these operations.
13.1.1 YUTAKI S
13.1.1.1 Removing the indoor unit service cover
? NOTE
The indoor unit service cover needs to be removed for any task inside the indoor unit.
1 Remove the screws which x the service cover.
(x2) Both sides
2 Slide the service cover slightly upward and remove it pulling to back.
! CAUTION
• Pay attention of no falling off the service cover.
• Take care when removing service cover; the parts inside the unit could be hot.
