7 ELECTRICAL AND CONTROL SETTINGS
7.1 GENERAL CHECK
Make sure that the following conditions related to power supply installation are satised:
- The power capacity of the electrical installation is large enough to support the power demand of the YUTAKI system (outdoor
unit + indoor unit + DHW tank (if apply)).
- The power supply voltage is within ±10% of the rated voltage.
- The impedance of the power supply line is low enough to avoid any voltage drop of more than 15% of the rated voltage.
Following the Council Directive 2004/108/EC, relating to electromagnetic compatibility, the table below indicates the Maximum
permitted system impedance Z
max
at the interface point of the user’s supply, in accordance with EN61000-3-11.
Split system - R410A Outdoor unit
Model Power supply Z
max
(Ω)
RAS-4WHVNPE
1~ 230V 50Hz
0.25
RAS-5WHVNPE 0.25
RAS-6WHVNPE 0.25
RAS-4WHNPE
3N~ 400V 50Hz
-
RAS-5WHNPE -
RAS-6WHNPE -
RAS-8WHNPE -
RAS-10WHNPE -
Split system - R32 Outdoor unit
Model Power supply Z
max
(Ω)
RAS-2WHVRP1
1~ 230V 50Hz
-
RAS-2.5WHVRP1 -
RAS-3WHVRP1 0.43
Split system - Indoor unit
YUTAKI S
Model Power supply Operation mode Z
max
(Ω)
RWM-(2.0-3.0)R1E 1~ 230V 50Hz
Without electric heater -
With electric heater -
With DHW tank heater -
With electric and DHW tank heaters 0.28
RWM-(2.0-3.0)R1E 3N~ 400V 50Hz
Without electric heater -
With electric heater -
With DHW tank heater -
With electric and DHW tank heaters -
RWM-(4.0-6.0)N1E
1~ 230V 50Hz
Without electric heater -
With electric heater 0.28
With DHW tank heater -
With electric and DHW tank heaters 0.19
3N~ 400V 50Hz
Without electric heater -
With electric heater -
With DHW tank heater -
With electric and DHW tank heaters -
RWM-(8.0/10.0)N1E 3N~ 400V 50Hz
Without electric heater -
With electric heater -
With DHW tank heater -
With electric and DHW tank heaters -
ELECTRICAL AND CONTROL SETTINGS
PMML0575 rev.2 - 03/2022
72
