7.2.2 Minimum requirements of the protection devices
! CAUTION
• Ensure specically that there is an Earth Leakage Breaker (ELB) installed for the units (outdoor and indoor unit).
• If the installation is already equipped with an Earth Leakage Breaker (ELB), ensure that its rated current is large enough to hold the current of the
units (outdoor and indoor unit).
? NOTE
• Electric fuses can be used instead of magnetic Circuit Breakers (CB). In that case, select fuses with similar rated values as the CB.
• The Earth Leakage Breaker (ELB) mentioned on this manual is also commonly known as Residual Current Device (RCD) or Residual Current
Circuit Breaker (RCCB).
• The Circuit Breakers (CB) are also known as Thermal-Magnetic Circuit Breakers or just Magnetic Circuit Breakers (MCB).
Split system - R410A Outdoor unit
Model Power supply
Applicable voltage
MC
(A)
CB
(A)
ELB
(nº of poles/A/mA)
U max. (V) U min. (V)
RAS-4WHVNPE
1~ 230V 50Hz 253 207
30 32
2/40/30RAS-5WHVNPE 30 32
RAS-6WHVNPE 30 32
RAS-4WHNPE
3N~ 400V 50Hz 440 360
14 15
4/40/30
RAS-5WHNPE 14 15
RAS-6WHNPE 16 20
RAS-8WHNPE 24 25
RAS-10WHNPE 24 25
MC: Maximum current; CB: Circuit breaker; ELB: Earth leakage breaker
Split system - R32 Outdoor unit
Model Power supply
Applicable voltage
MC
(A)
CB
(A)
ELB
(nº of poles/A/mA)
U max. (V) U min. (V)
RAS-2WHVRP1
1~ 230V 50Hz 253 207
10 16
2/40/30RAS-2.5WHVRP1 13 16
RAS-3WHVRP1 16 20
MC: Maximum current; CB: Circuit breaker; ELB: Earth leakage breaker
ELECTRICAL AND CONTROL SETTINGS
PMML0575 rev.2 - 03/2022
80
