Hitachi YUTAKI RWM-2R1E User Manual

ENGLISH

Split system - Indoor unit
YUTAKI S
Model Power supply
Applicable voltage
Operation mode
MC
(A)
CB
(A)
ELB
(nº of poles/A/mA)
U max.
(V)
U min.
(V)
RWM-(2.0-3.0)R1E 1~ 230V 50Hz 253 207
Without electric heaters 0.6 5
2/40/30
With electric heater 14 16
With DHW tank heater
14
16
With electric and DHW tank heaters 27 32
RWM-(2.0-3.0)R1E 3N~ 400V 50Hz 440 360
Without electric heaters 0.6 5
4/40/30
With electric heater 5 10
With DHW tank heater 14 15
With electric and DHW tank heaters 18 25
RWM-(4.0-6.0)N1E
1~ 230V 50Hz 253 207
Without electric heaters 0.7 5
2/40/30With electric heater 27 32
With DHW tank heater 14 16
With electric and DHW tank heaters 40 50 2/63/30
3N~ 400V 50Hz 440 360
Without electric heaters
0.7
5
4/40/30
With electric heater 9 15
With DHW tank heater 14 15
With electric and DHW tank heaters 22 25
RWM-(8.0/10.0)N1E 3N~ 400V 50Hz 440 360
Without electric heaters 0.7 5
4/40/30
With electric heater 14 20
With DHW tank heater 14 20
With electric and DHW tank heaters 27 30
? NOTE
The data corresponding to DHW tank heater is calculated in combination with the domestic hot water tank accessory “DHWT-(200/300)S-3.0H2E”.
YUTAKI S COMBI
Model Power supply
Applicable voltage
Operation mode
MC
(A)
CB
(A)
ELB
(nº of poles/A/mA)
U max.
(V)
U min.
(V)
RWD-(2.0-3.0)RW1E-
220(-K)
1~ 230V 50Hz 253 207
Without electric heaters 0.6
5
2/40/30
With electric heater 13.7
16
With DHW tank heater 12.6
16
With electric and DHW tank heaters 25.6
32
RWD-(2.0-3.0)RW1E-
220(-K)
3N~ 400V 50Hz 440 360
Without electric heaters 0.6 5
4/40/30
With electric heater 9.3 15
With DHW tank heater 12.6 15
With electric and DHW tank heaters 12.6 15
RWD-(4.0-6.0)NW1E-
220S(-K)
1~ 230V 50Hz 253 207
Without electric heaters 0.7 5
2/40/30With electric heater 26.7 32
With DHW tank heater 12.6 16
With electric and DHW tank heaters 38.7 50 2/63/30
3N~ 400V 50Hz 440 360
Without electric heaters 0.7 5
4/40/30
With electric heater 18.0 25
With DHW tank heater 12.6 15
With electric and DHW tank heaters 18.0 25
ELECTRICAL AND CONTROL SETTINGS
PMML0575 rev.2 - 03/2022
81
