11 YUTAKI CASCADE CONTROLLER ATW-YCC-03
The new YUTAKI CASCADE CONTROLLER for YUTAKI series (PC-ARFH2E) is an user-friendly remote control which ensures a
strong and safe communication through H-LINK.
Available for the following unit models:
• RWM-(2.0-3.0)N1E
• RWD-(2.0-3.0)RW1E-220S(-K)
11.1 DEFINITION OF THE SWITCHES
Liquid Crystal Display
Screen where controller software is displayed.
OK button
To select the variables to be edited and to conrm the selected values.
Arrows key
It helps the user to move through the menus and views.
Run/Stop button
It works for all zones if none of the zones is selected or only for one zone when that zone is selected.
Return button
To return to the previous screen.
YUTAKI CASCADE CONTROLLER ATW-YCC-03
PMML0575 rev.2 - 03/2022
266
